EVOLUTION SERIES

Evolution Series Spray Guns are intelligently designed to provide the user with their spray coating requirements. The HVLP Spray Guns are used for more efficient application resulting in higher transfer efficiency, reduced overspray, material consumption and pollution, while HP Spray Guns integrate the benefits of HVLP & Legacy Series ensuring high quality finishing and transfer efficiency.

EVOLUTION

SERIES

Evolution series spray guns are used where high-quality surface coating is paramount. They are used in places where superior atomization is required in surface coating. Ideal for finer and more efficient application, these guns offer superior finishing, higher transfer efficiency, reduced overspray & material consumption. The Evolution series causes less pollution.

HVLP 03

(High Volume Low Pressure)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • High transfer efficiency with minimum wastage
TECHNICAL DATA
Code No. HVLP03000P
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Material output (cc/min) 250
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 727
pdf 1 - Pilot India  Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sports - Pilot IndiaSports

HVLP 03

(High Volume Low Pressure)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • High transfer efficiency with minimum wastage

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
HVLP 03 - Pilot India
TECHNICAL DATA
Code No. HVLP03000P
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Material output (cc/min) 250
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 761

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual

HVLP 06

(High Volume Low Pressure)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in spreader control facilitating round & fan flow patterns
  • High transfer efficiency with minimum wastage
TECHNICAL DATA
Code No. HVLP06000
Cup capacity (litres)- 0.35
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.0
Required pressure (kgs/sq.cm) 2-3
Air consumption of rated pressure lit/min (c.f.m) 115-170 (4-6)
Material output (cc/min) 4-6
Max. pattern width (mm) 300
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 353
pdf 1 - Pilot India   Download Catalogue

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sports - Pilot IndiaSports

HVLP 06

(High Volume Low Pressure)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in spreader control facilitating round & fan flow patterns
  • High transfer efficiency with minimum wastage

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
HVLP 06 - Pilot India
TECHNICAL DATA
Code No. HVLP06000
Cup capacity (litres)- 0.35
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.0
Required pressure (kgs/sq.cm) 2-3
Air consumption of rated pressure lit/min (c.f.m) 115-170 (4-6)
Material output (cc/min) 4-6
Max. pattern width (mm) 300
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 353

pdf 1 - Pilot India   Download Catalogue

HVLP 08

(High Volume Low Pressure)


FEATURES
  • Large surface area coverage
  • Symmetric & durable suction feed cup
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • High transfer efficiency with minimum wastage
  • Compatibility with pressure feed tanks
TECHNICAL DATA
Code No. HVLP08000
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 995
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sports - Pilot IndiaSports

HVLP 08

(High Volume Low Pressure)


FEATURES
  • Large surface area coverage
  • Symmetric & durable suction feed cup
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • High transfer efficiency with minimum wastage
  • Compatibility with pressure feed tanks

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
HVLP 08 - Pilot India
TECHNICAL DATA
Code No. HVLP08000
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 995

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual

HVLP 08 WITHOUT CUP

(High Volume Low Pressure)


FEATURES
  • Large surface area coverage
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • High transfer efficiency with minimum wastage
  • Compatibility with pressure feed tanks
TECHNICAL DATA
Code No. HVLP08000 w/c
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 673
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sports - Pilot IndiaSports

HVLP 08 WITHOUT CUP

(High Volume Low Pressure)


FEATURES
  • Large surface area coverage
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • High transfer efficiency with minimum wastage
  • Compatibility with pressure feed tanks

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
HVLP 08 with cup - Pilot India
TECHNICAL DATA
Code No. HVLP08000 w/c
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 673

pdf 1 - Pilot India  Download Catalogue
pdf 1 - Pilot India  Download Manual

HP 59 N

(High Performance)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • Optimum for high speed production
TECHNICAL DATA
Code No. HP59000N
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 225-283 (8-10)
Max. pattern width (mm) 300
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 653
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sports - Pilot IndiaSports

HP 59 N

(High Performance)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in air & spreader control for finer adjustment
  • Optimum for high speed production

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
HP 59 N 1 - Pilot India
TECHNICAL DATA
Code No. HP59000N
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 225-283 (8-10)
Max. pattern width (mm) 300
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 653

pdf 1 - Pilot India   Download catalogue
pdf 1 - Pilot India   Download manual

HP 64 N

(High Performance)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in spreader control facilitating round & fan flow patterns
  • Ideal for small to medium sized surfaces
TECHNICAL DATA
Code No. HP64000N
Cup capacity (litres)- 0.35
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2-3
Air consumption of rated pressure lit/min (c.f.m) 115-170 (4-6)
Material output (cc/min) 300
Max. pattern width (mm) 250
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 353
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Sports - Pilot IndiaSports Automobiles - Pilot India
Automobiles
Handicrafts - Pilot India
Handicrafts
Furniture - Pilot India
Furniture
Electrical equipment - Pilot IndiaElectrical Equipment

HP 64 N

(High Performance)


FEATURES
  • Lightweight sleek ergonomic design
  • Symmetric & durable gravity cup
  • Superior air cap performance
  • Built-in spreader control facilitating round & fan flow patterns
  • Ideal for small to medium sized surfaces

AREAS OF APPLICATION

Electrical equipment - Pilot India
Electrical Equipment
Handicrafts - Pilot India
Handicrafts
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
HP 64 N - Pilot India
TECHNICAL DATA
Code No. HP64000N
Cup capacity (litres)- 0.35
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2-3
Air consumption of rated pressure lit/min (c.f.m) 115-170 (4-6)
Material output (cc/min) 300
Max. pattern width (mm) 250
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 353

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual

HP 68 N

(High Performance)


FEATURES
  • Lightweight sleek ergonomic design for precision work
  • Symmetric & durable gravity cup
  • Built-in air control for finer adjustment
  • Permits exquisite shading & blending
  • Accurate & easy trigger control
    TECHNICAL DATA
    Code No. HP68000N
    Cup capacity (litres)- 0.14
    Gun distance from work piece mm(inch) – 228.6(9)
    Fluid nozzle orifice dia. (mm) 0.8
    Required pressure (kgs/sq.cm) 1-2.5
    Air consumption of rated pressure lit/min (c.f.m) 55-115 (2-4)
    Material output (cc/min) 85
    Max. pattern width (mm) 100
    Min. Air-compressor (HP) 1
    Weight of gun with cup (gms) 295
    pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

    AREAS OF APPLICATION

    Sculpture 2 - Pilot IndiaStatues Artistry - Pilot India
    Artistry
    - Pilot India
    Textile
    Handicrafts - Pilot India
    Handicrafts
    Laboratory - Pilot IndiaLaboratory

    HP 68 N

    (High Performance)


    FEATURES
    • Lightweight sleek ergonomic design for precision work
    • Symmetric & durable gravity cup
    • Built-in air control for finer adjustment
    • Permits exquisite shading & blending
    • Accurate & easy trigger control

      AREAS OF APPLICATION

      Sculpture 2 - Pilot India
      Statues
      - Pilot India
      Textile
      Artistry - Pilot India
      Artistry
      Handicrafts - Pilot India
      Handicrafts
      Laboratory - Pilot India
      Laboratory
      HP 68 N - Pilot India
      TECHNICAL DATA
      Code No. HP68000N
      Cup capacity (litres)- 0.14
      Gun distance from work piece mm(inch) – 228.6(9)
      Fluid nozzle orifice dia. (mm) 0.8
      Required pressure (kgs/sq.cm) 1-2.5
      Air consumption of rated pressure lit/min (c.f.m) 55-115 (2-4)
      Material output (cc/min) 85
      Max. pattern width (mm) 100
      Min. Air-compressor (HP) 1
      Weight of gun with cup (gms) 295

      pdf 1 - Pilot India   Download Catalogue
      pdf 1 - Pilot India   Download Manual

      HP P-70

      (High Performance)


      FEATURES
      • Large surface area coverage
      • Symmetric & durable suction feed cup
      • Superior air cap performance
      • Built-in air & spreader control for finer adjustment
      • Optimum for high speed production
      • Compatibility with pressure feed tanks

      AREAS OF APPLICATION

      Industrial - Pilot India
      Industries
      Railways - Pilot India
      Railways
      Automobiles - Pilot India
      Automobiles
      Ship Building - Pilot India
      Ship-Building
      HP P 70 with cup - Pilot India
      TECHNICAL DATA
      Code No. HP70000
      Cup capacity (litres)- 1
      Gun distance from work piece mm(inch) – 228.6(9)
      Fluid nozzle orifice dia. (mm) 1.6
      Required pressure (kgs/sq.cm) 2.5-5
      Air consumption of rated pressure lit/min (c.f.m) 200-283 (7-10)
      Material output (cc/min) 200
      Max. pattern width (mm) 360
      Min. Air-compressor (HP) 2
      Weight of gun with cup (gms) 983

      pdf 1 - Pilot India   Download Catalogue

      HP P-70 W/O CUP

      (High Performance)


      FEATURES
      • Large surface area coverage
      • Superior air cap performance
      • Built-in air & spreader control for finer adjustment
      • Optimum for high speed production
      • Compatibility with pressure feed tanks

      AREAS OF APPLICATION

      Industrial - Pilot India
      Industries
      Railways - Pilot India
      Railways
      Automobiles - Pilot India
      Automobiles
      Ship Building - Pilot India
      Ship-Building
      HP P 70 1 - Pilot India
      TECHNICAL DATA
      Code No. HP70000 w/c
      Cup capacity (litres)- 1
      Gun distance from work piece mm(inch) – 228.6(9)
      Fluid nozzle orifice dia. (mm) 1.7
      Required pressure (kgs/sq.cm) 2.5-5
      Air consumption of rated pressure lit/min (c.f.m) 200-283 (7-10)
      Material output (cc/min) 200
      Max. pattern width (mm) 360
      Min. Air-compressor (HP) 2
      Weight of gun (gms) 660

      pdf 1 - Pilot India   Download Catalogue

      HP P-70

      (High Performance)


      FEATURES
      • Large surface area coverage
      • Symmetric & durable suction feed cup
      • Superior air cap performance
      • Built-in air & spreader control for finer adjustment
      • Optimum for high speed production
      • Compatibility with pressure feed tanks
      TECHNICAL DATA
      Code No. HP70000
      Cup capacity (litres)- 1
      Gun distance from work piece mm(inch) – 228.6(9)
      Fluid nozzle orifice dia. (mm) 1.6
      Required pressure (kgs/sq.cm) 2.5-5
      Air consumption of rated pressure lit/min (c.f.m) 200-283 (7-10)
      Material output (cc/min) 200
      Max. pattern width (mm) 360
      Min. Air-compressor (HP) 2
      Weight of gun with cup (gms) 983
      pdf 1 - Pilot India   Download Catalogue

      AREAS OF APPLICATION

      Industrial - Pilot India
      Industries
      Automobiles - Pilot India
      Automobiles
      Railways - Pilot India
      Railways
      Ship Building - Pilot India
      Ship-Building

      HP P-70 W/O CUP

      (High Performance)


      FEATURES
      • Large surface area coverage
      • Superior air cap performance
      • Built-in air & spreader control for finer adjustment
      • Optimum for high speed production
      • Compatibility with pressure feed tanks
      TECHNICAL DATA
      Code No. HP70000 w/c
      Cup capacity (litres)- 1
      Gun distance from work piece mm(inch) – 228.6(9)
      Fluid nozzle orifice dia. (mm) 1.7
      Required pressure (kgs/sq.cm) 2.5-5
      Air consumption of rated pressure lit/min (c.f.m) 200-283 (7-10)
      Material output (cc/min) 200
      Max. pattern width (mm) 360
      Min. Air-compressor (HP) 2
      Weight of gun (gms) 660
      pdf 1 - Pilot India   Download Catalogue

      AREAS OF APPLICATION

      Industrial - Pilot India
      Industries
      Automobiles - Pilot India
      Automobiles
      Railways - Pilot India
      Railways
      Ship Building - Pilot India
      Ship-Building
