LEGACY SERIES

The Legacy Series consists of PILOT’s Iconic range of Spray Guns which typically operate at higher air pressures and are used for coating any type of surface/object. High air pressure results in super fine atomization resulting in a smoother & high quality spray finish

LEGACY

SERIES

Standard or Conventional spray guns typically operate at higher air pressure and are used for coating any type of surface/object. High air pressure results in super fine atomization resulting in a smoother spray finish.

TYPE 59 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Balanced handle for comfortable & firm grip
  • Built-in spreader control for round & fan flow patterns

TECHNICAL DATA

Code No. 59000N
Cup capacity (litres) 0.57
Gun distance from work piece mm (inch) 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 4
Air consumption of rated pressure lit/min (c.f.m) 300-310 (10)
Material output (cc/min) 265
Max. pattern width (mm) 355
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 640
   Download Catalogue    Download Manual

AREAS OF APPLICATION


Industries

Automobiles

Textile

Furniture
Pharmaceuticals



TYPE 59 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Balanced handle for comfortable & firm grip
  • Built-in spreader control for round & fan flow patterns
AREAS OF APPLICATION

Industries

Textile

Automobiles

Furniture

Pharmaceuticals

TECHNICAL DATA

Code No. 59000N
Cup capacity (litres) 0.57
Gun distance from work piece mm (inch) 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 4
Air consumption of rated pressure lit/min (c.f.m) 300-310 (10)
Material output (cc/min) 265
Max. pattern width (mm) 355
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 640

   Download Catalogue   Download Manual

TYPE 59 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Balanced handle for comfortable & firm grip
  • Symmetric & durable gravity cup
  • Built-in spreader control for round & fan flow patterns

TECHNICAL DATA

Code No. 59000S
Cup capacity (litres) 0.57
Gun distance from work piece mm (inch) 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 4
Air consumption of rated pressure lit/min (c.f.m) 300-310 (10)
Material output (cc/min) 265
Max. pattern width (mm) 355
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 728
   Download Catalogue    Download Manual

AREAS OF APPLICATION


Industries

Automobiles

Textile

Furniture
Pharmaceuticals

TYPE 59 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Balanced handle for comfortable & firm grip
  • Symmetric & durable gravity cup
  • Built-in spreader control for round & fan flow patterns

AREAS OF APPLICATION


Industries

Textile
Pharmaceuticals

Furniture

Automobiles

TECHNICAL DATA

Code No. 59000S
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 4
Air consumption of rated pressure lit/min (c.f.m) 300-310 (10)
Material output (cc/min) 265
Max. pattern width (mm) 355
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 728

   Download Catalogue
   Download Manual

TYPE 64 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern

TECHNICAL DATA

Code No. 64000N
Cup capacity (litres) 0.34
Gun distance from work piece mm (inch) 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 3
Air consumption of rated pressure lit/min (c.f.m) 200- 210(7)
Material output (cc/min) 260
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 360
   Download Catalogue    Download Manual

AREAS OF APPLICATION


Electrical

Automobiles

Handicrafts

Furniture
Sports Goods

TYPE 64 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern

AREAS OF APPLICATION


Electrical

Handicraft

Automobiles

Furniture

Sports

TECHNICAL DATA

Code No. 64000N
Cup capacity (litres) 0.34
Gun distance from work piece mm (inch) 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 3
Air consumption of rated pressure lit/min (c.f.m) 200- 210 (7)
Material output (cc/min) 260
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 360

   Download Catalogue

   Download Manual

TYPE 64 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern

TECHNICAL DATA

Code No. 64000S
Cup capacity (litres) 0.34
Gun distance from work piece mm (inch) 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 3
Air consumption of rated pressure lit/min (c.f.m) 200-210 (7)
Material output (cc/min) 260
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 449
   Download Catalogue    Download Manual

AREAS OF APPLICATION


Electrical

Automobiles

Handicrafts

Furniture
Sports Goods

TYPE 64 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern

AREAS OF APPLICATION


Electrical

Handicraft

Automobiles

Furniture

Sports

TECHNICAL DATA

Code No. 64000S
Cup capacity (litres) 0.34
Gun distance from work piece mm (inch) 200 (8)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2 – 3
Air consumption of rated pressure lit/min (c.f.m) 200- 210 (7)
Material output (cc/min) 260
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 449

   Download Catalogue
   Download Manual

TYPE 68 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Lightweight sleek ergonomic design for precision work
  • Symmetric & durable gravity cup
  • Built-in air control for finer adjustment
  • Permits exquisite shading & blending
  • Accurate & easy trigger control

      TECHNICAL DATA

      Code No. 68000N
      Cup capacity (litres)- 0.14
      Gun distance from work piece mm(inch) – 200 (8)
      Fluid nozzle orifice dia. (mm) 0.8
      Required pressure (kgs/sq.cm) 2 – 3
      Air consumption of rated pressure lit/min (c.f.m) 60-70 (2)
      Material output (cc/min) 100
      Max. pattern width (mm) 100
      Min. Air-compressor (HP) 1
      Weight of gun with cup (gms) 287
         Download Catalogue    Download Manual

      AREAS OF APPLICATION

      Artistry
      Handicrafts

      Textile

      Laboratory
      Pottery

      TYPE 68 S

      (Spray Gun)


      FEATURES
      • Iconic design & performance
      • Lightweight sleek ergonomic design for precision work
      • Symmetric & durable gravity cup
      • Built-in air control for finer adjustment
      • Permits exquisite shading & blending
      • Accurate & easy trigger control

          TECHNICAL DATA

          Code No. 68000S
          Cup capacity (litres)- 0.14
          Gun distance from work piece mm(inch) – 200 (8)
          Fluid nozzle orifice dia. (mm) 0.8
          Required pressure (kgs/sq.cm) 2 – 3
          Air consumption of rated pressure lit/min (c.f.m) 60-70 (2)
          Material output (cc/min) 100
          Max. pattern width (mm) 100
          Min. Air-compressor (HP) 1
          Weight of gun with cup (gms) 330
             Download Catalogue    Download Manual

          AREAS OF APPLICATION

          Artistry
          Handicrafts

          Textile

          Laboratory
          Pottery

          TYPE 68 N

          (Spray Gun)


          FEATURES
          • Iconic design & performance
          • Lightweight sleek ergonomic design for precision work
          • Symmetric & durable gravity cup
          • Built-in air control for finer adjustment
          • Permits exquisite shading & blending
          • Accurate & easy trigger control

              AREAS OF APPLICATION


              Artistry

              Textile

              Laboratory

              Handicrafts

              Pottery

              TECHNICAL DATA

              Code No. 68000N
              Cup capacity (litres)- 0.14
              Gun distance from work piece mm(inch) – 200 (8)
              Fluid nozzle orifice dia. (mm) 0.8
              Required pressure (kgs/sq.cm) 2 – 3
              Air consumption of rated pressure lit/min (c.f.m) 60-70 (2)
              Material output (cc/min) 100
              Max. pattern width (mm) 100
              Min. Air-compressor (HP) 1
              Weight of gun with cup (gms) 287

                 Download Catalogue
                 Download Manual

              TYPE 68 S

              (Spray Gun)


              FEATURES
                • Iconic design & performance
                • Lightweight sleek ergonomic design for precision work
                • Symmetric & durable gravity cup
                • Built-in air control for finer adjustment
                • Permits exquisite shading & blending
                • Accurate & easy trigger control

                    AREAS OF APPLICATION


                    Artistry

                    Textile

                    Laboratory

                    Handicrafts

                    Pottery

                    TECHNICAL DATA

                    Code No. 68000S
                    Cup capacity (litres)- 0.14
                    Gun distance from work piece mm(inch) – 200 (8)
                    Fluid nozzle orifice dia. (mm) 0.8
                    Required pressure (kgs/sq.cm) 2 – 3
                    Air consumption of rated pressure lit/min (c.f.m) 60-70 (2)
                    Material output (cc/min) 100
                    Max. pattern width (mm) 100
                    Min. Air-compressor (HP) 1
                    Weight of gun with cup (gms) 330

                       Download Catalogue
                       Download Manual

                    TYPE P-70 WITH CUP

                    (Spray Gun)


                    FEATURES
                    • Iconic design & performance
                    • Large surface area coverage
                    • Symmetric & durable suction feed cup
                    • Superior air cap performance
                    • Built-in spreader control for round & fan flow patterns
                    • Optimum for high speed production
                    • Compatibility with pressure feed tanks

                    TECHNICAL DATA

                    Code No. 70000
                    Cup capacity (litres) 1
                    Gun distance from work piece mm (inch) 200 (8)
                    Fluid nozzle orifice dia. (mm) 1.6
                    Required pressure (kgs/sq.cm) 2.5-5
                    Air consumption of rated pressure lit/min (c.f.m) 290-300 (10)
                    Material output (cc/min) 315
                    Max. pattern width (mm) 305
                    Min. Air-compressor (HP) 2
                    Weight of gun with cup (gms) 945
                       Download Catalogue    Download Manual

                    AREAS OF APPLICATION


                    Industries

                    Automobiles

                    Railways

                    Ship-Building

                    TYPE P-70 WITH CUP

                    (Spray Gun)


                    FEATURES
                    • Iconic design & performance
                    • Large surface area coverage
                    • Symmetric & durable suction feed cup
                    • Superior air cap performance
                    • Built-in spreader control for round & fan flow patterns
                    • Optimum for high speed production
                    • Compatibility with pressure feed tanks
                    AREAS OF APPLICATION

                    Industries

                    Railways

                    Automobiles

                    Ship-Building

                    TECHNICAL DATA

                    Code No. 70000
                    Cup capacity (litres) 1
                    Gun distance from work piece mm (inch) 200 (8)
                    Fluid nozzle orifice dia. (mm) 1.6
                    Required pressure (kgs/sq.cm) 2.5-5
                    Air consumption of rated pressure lit/min (c.f.m) 290-300 (10)
                    Material output (cc/min) 310
                    Max. pattern width (mm) 305
                    Min. Air-compressor (HP) 2
                    Weight of gun with cup (gms) 945

                       Download Catalogue
                       Download Manual

                    TYPE P-70 WITHOUT CUP

                    (Spray Gun)


                    FEATURES
                    • Iconic design & performance
                    • Large surface area coverage
                    • Superior air cap performance
                    • Built-in spreader control for round & fan flow patterns
                    • Optimum for high speed production
                    • Compatibility with pressure feed tanks

                        TECHNICAL DATA

                        Code No. 70000WC
                        Gun distance from work piece mm (inch) 200 (8)
                        Fluid nozzle orifice dia. (mm) 1.6
                        Required pressure (kgs/sq.cm) 2.5-5
                        Air consumption of rated pressure lit/min (c.f.m) 290-300 (10)
                        Material output (cc/min) 315
                        Max. pattern width (mm) 305
                        Min. Air-compressor (HP) 2
                        Weight of gun with cup (gms) 630
                           Download Catalogue    Download Manual

                        AREAS OF APPLICATION


                        Industries

                        Automobiles

                        Railways

                        Ship-Building

                        TYPE P-70 WITHOUT CUP

                        (Spray Gun)


                        FEATURES
                        • Iconic design & performance
                        • Large surface area coverage
                        • Superior air cap performance
                        • Built-in spreader control for round & fan flow patterns
                        • Optimum for high speed production
                        • Compatibility with pressure feed tanks



                              AREAS OF APPLICATION


                              Industries

                              Railways

                              Automobiles

                              Ship-Building

                              TECHNICAL DATA

                              Code No. 70000WC
                              Gun distance from work piece mm(inch) – 200 (8)
                              Fluid nozzle orifice dia. (mm) 1.6
                              Required pressure (kgs/sq.cm) 2.5-5
                              Air consumption of rated pressure lit/min (c.f.m) 290-300 (10)
                              Material output (cc/min) 315
                              Max. pattern width (mm) 305
                              Min. Air-compressor (HP) 2
                              Weight of gun with cup (gms) 630

                                 Download Catalogue
                                 Download Manual

                              TYPE P-80

                              (Spray Gun)


                              FEATURES
                              • Large surface area coverage
                              • Symmetric & durable gravity cup (large size)
                              • Superior air cap performance
                              • Built-in spreader control for round & fan flow patterns
                              • Optimum for high speed production

                              TECHNICAL DATA

                              Code No. 80000
                              Cup capacity (litres) 0.75
                              Gun distance from work piece mm (inch) 200 (8)
                              Fluid nozzle orifice dia. (mm) 1.6
                              Required pressure (kgs/sq.cm) 2.5-5
                              Air consumption of rated pressure lit/min (c.f.m) 260-270 (9)
                              Material output (cc/min) 400
                              Max. pattern width (mm) 305
                              Min. Air-compressor (HP) 2
                              Weight of gun with cup (gms) 768
                                 Download Catalogue    Download Manual

                              AREAS OF APPLICATION


                              Industries

                              Automobiles

                              Chemicals

                              Ship-Building

                              TYPE P-80

                              (Spray Gun)


                              FEATURES
                              • Large surface area coverage
                              • Symmetric & durable gravity cup (large size)
                              • Superior air cap performance
                              • Built-in spreader control for round & fan flow patterns
                              • Optimum for high speed production

                              AREAS OF APPLICATION


                              Industries

                              Chemicals

                              Automobiles

                              Ship-Building

                              TECHNICAL DATA

                              Code No. 80000
                              Cup capacity (litres) 0.75
                              Gun distance from work piece mm (inch) 200 (8)
                              Fluid nozzle orifice dia. (mm) 1.6
                              Required pressure (kgs/sq.cm) 2.5-5
                              Air consumption of rated pressure lit/min (c.f.m) 260-270 (9)
                              Material output (cc/min) 400
                              Max. pattern width (mm) 305
                              Min. Air-compressor (HP) 2
                              Weight of gun with cup (gms) 768

                                 Download Catalogue
                                 Download Manual
