AIR BRUSH SERIES

Airbrush is an indispensable tool for those who demand absolute precision for extremely delicate & detailed spraying applications. The PILOT Airbrush Series offer complete control and versatility to creative and experienced spray artists.

AIR BRUSH

SERIES

Airbrush is an indispensable tool for those who demand absolute precision for extremely delicate & detailed spraying applications. The PILOT Airbrush Seriesoffer complete control and versatility to creative and experienced spray artists.

AB-10 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well
    designed
    dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

TECHNICAL DATA

Code No. AB-10 Pro
Cup capacity approx (ml)- 5
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 103
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food
decoration
Makeup body art tanning - Pilot India
Makeup, body
art & tanning
Design Fashion Studios - Pilot India
Design &
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio

AB-10 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food decoration
Makeup body art tanning - Pilot India
Makeup, body art & tanning
Design Fashion Studios - Pilot India
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio
AB 10 pro - Pilot India

TECHNICAL DATA

Code No. AB-10 Pro
Cup capacity approx (ml)- 5
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 103

pdf 1 - Pilot India   Download Catalogue

pdf 1 - Pilot India   Download Manual

AB-12 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

TECHNICAL DATA

Code No. AB-12 PRO
Cup capacity approx (ml)- 10
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 123
pdf 1 - Pilot India  Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food
decoration
Makeup body art tanning - Pilot India
Makeup, body
art & tanning
Design Fashion Studios - Pilot India
Design &
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio

AB-12 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food decoration
Makeup body art tanning - Pilot India
Makeup, body art & tanning
Design Fashion Studios - Pilot India
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio
AB 12 pro - Pilot India

TECHNICAL DATA

Code No. AB-12 PRO
Cup capacity approx (ml)- 10
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 123

pdf 1 - Pilot India  Download Catalogue
pdf 1 - Pilot India   Download Manual

AB-15 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

TECHNICAL DATA

Code No. AB-15 PRO
Cup capacity approx (ml)- 10
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 136
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food
decoration
Makeup body art tanning - Pilot India
Makeup, body
art & tanning
Design Fashion Studios - Pilot India
Design &
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio

AB-15 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food decoration
Makeup body art tanning - Pilot India
Makeup, body art & tanning
Design Fashion Studios - Pilot India
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio
AB 15 pro - Pilot India

TECHNICAL DATA

Code No. AB-15 PRO
Cup capacity approx (ml)- 15
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 136

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual

AB-16 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

TECHNICAL DATA

Code No. AB-16 Pro
Cup capacity approx (ml)- 30/60
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.5
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 12
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 208
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food
decoration
Makeup body art tanning - Pilot India
Makeup, body
art & tanning
Design Fashion Studios - Pilot India
Design &
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio

AB-16 PRO

(Air Brush – Professional Series)


FEATURES
  • Built-in air control for finer adjustment
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.
AREAS OF APPLICATION
Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food decoration
Makeup body art tanning - Pilot India
Makeup, body art & tanning
Design Fashion Studios - Pilot India
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio
AB 16 pro - Pilot India

TECHNICAL DATA

Code No. AB-16 Pro
Cup capacity approx (ml)- 30/60
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.5
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 12
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 208

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual

AB-10

(Air Brush)


FEATURES
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

TECHNICAL DATA

Code No. AB-10
Cup capacity approx (ml)- 5
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Min. Air-compressor (HP) 2
Weight of gun (gms) 105
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food
decoration
Makeup body art tanning - Pilot India
Makeup, body
art & tanning
Design Fashion Studios - Pilot India
Design &
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio

AB-10

(Air Brush)


FEATURES
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food decoration
Makeup body art tanning - Pilot India
Makeup, body art & tanning
Design Fashion Studios - Pilot India
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio
AB 10 - Pilot India

TECHNICAL DATA

Code No. AB-10
Cup capacity approx (ml)- 5
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Min. Air-compressor (HP) 2
Weight of gun (gms) 105

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual

AB-12

(Air Brush)


FEATURES
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

TECHNICAL DATA

Code No. AB-12
Cup capacity approx (ml)- 10
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 118
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food
decoration
Makeup body art tanning - Pilot India
Makeup, body
art & tanning
Design Fashion Studios - Pilot India
Design &
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio

AB-12

(Air Brush)


FEATURES
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food decoration
Makeup body art tanning - Pilot India
Makeup, body art & tanning
Design Fashion Studios - Pilot India
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio
AB 12 - Pilot India

TECHNICAL DATA

Code No. AB-12
Cup capacity approx (ml)- 10
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 118

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual

AB-15

(Air Brush)


FEATURES
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

TECHNICAL DATA

Code No. AB-15
Cup capacity approx (ml)- 15
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 135
pdf 1 - Pilot India   Download Catalogue pdf 1 - Pilot India   Download Manual

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food
decoration
Makeup body art tanning - Pilot India
Makeup, body
art & tanning
Design Fashion Studios - Pilot India
Design &
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio

AB-15

(Air Brush)


FEATURES
  • Lightweight & ergonomically well designed dual action airbrush
  • Precision stainless steel needle & nozzle
  • Needle adjustment for fluid control
  • Suitable in precision artistic jobs for free-hand & stencil designing
  • Adaptable using any colouring agent: paints, inks, dyes, etc.

AREAS OF APPLICATION

Handicrafts - Pilot India
Art & Handicraft
Food decoration - Pilot India
Food decoration
Makeup body art tanning - Pilot India
Makeup, body art & tanning
Design Fashion Studios - Pilot India
Fashion Studios
Glass Industry - Pilot India
Glass Industry
Photo Studio - Pilot India
Photo Studio
AB 15 - Pilot India

TECHNICAL DATA

Code No. AB-15
Cup capacity approx (ml)- 15
Max. pattern width (mm) /Gun distance from work piece mm (inch) – 20/50(2)
Fluid nozzle orifice dia. (mm) 0.3
Min Required pressure (kgs/sq.cm) 1.5
Air consumption of rated pressure lit/min (c.f.m) 5(0.17)
Material output (cc/min) 2
Min. Air-compressor (HP) 1/8*
Weight of gun (gms) 135

pdf 1 - Pilot India   Download Catalogue
pdf 1 - Pilot India   Download Manual
