HVLP

TECHNOLOGY

Higher volume low pressure (HVLP) spray guns are used to aerosolize and propel the paint. This results in high proportion of paint reaching the target surface with reduced overspray, material consumption and air pollution.

HVLP

TECHNOLOGY

Higher volume low pressure (HVLP) spray guns are used to aerosolize and propel the paint. This results in high proportion of paint reaching the target surface with reduced overspray, material consumption and air pollution.

HVLP – 03

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Unique ACT (Air Circulation
Technology) air cap
TECHNICAL DATA
Code No. HVLP03000P
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Material output (cc/min) 250
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 761

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sculpture 2 - Pilot IndiaSculpture Sports - Pilot IndiaSports

HVLP – 03

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Unique ACT (Air Circulation Technology) air cap

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
Sculpture 2 - Pilot India
Sculpture
Edited bg - Pilot India
TECHNICAL DATA
Code No. HVLP03000P
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Material output (cc/min) 250
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 761

HVLP-06

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Unique ACT (Air Circulation
   Technology) air cap
TECHNICAL DATA
Code No. HVLP06000
Cup capacity (litres)- 0.35
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.0
Required pressure (kgs/sq.cm) 2-3
Air consumption of rated pressure lit/min (c.f.m) 115-170 (4-6)
Material output (cc/min) 4-6
Max. pattern width (mm) 300
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 330

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sculpture 2 - Pilot IndiaSculpture Sports - Pilot IndiaSports

HVLP – 06

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Unique ACT (Air Circulation Technology) air cap

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
Sculpture 2 - Pilot India
Sculpture
HVLP 06 - Pilot India
TECHNICAL DATA
Code No. HVLP06000
Cup capacity (litres)- 0.35
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.0
Required pressure (kgs/sq.cm) 2-3
Air consumption of rated pressure lit/min (c.f.m) 115-170 (4-6)
Material output (cc/min) 4-6
Max. pattern width (mm) 300
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 330

HVLP-08

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Superior Air Cap technology
TECHNICAL DATA
Code No. HVLP08000
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 1040

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sculpture 2 - Pilot IndiaSculpture Sports - Pilot IndiaSports

HVLP – 08

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Superior Air Cap technology

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
Sculpture 2 - Pilot India
Sculpture
HVLP 08 - Pilot India
TECHNICAL DATA
Code No. HVLP08000
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 1040

HVLP-08 WITHOUT CUP

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Superior Air Cap technology
TECHNICAL DATA
Code No. HVLP08000 w/c
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 695

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Sculpture 2 - Pilot IndiaSculpture Sports - Pilot IndiaSports

HVLP-08 WITHOUT CUP

(High Volume Low Pressure)


FEATURES
– Lightweight & sleek
– Symmetric gravity cup
– Superior Air Cap technology

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
Sculpture 2 - Pilot India
Sculpture
HVLP 08 with cup - Pilot India
TECHNICAL DATA
Code No. HVLP08000 w/c
Cup capacity (litres)- 1
Gun distance from work piece mm(inch) – 200(8)
Fluid nozzle orifice dia. (mm) 1.3
Required pressure (kgs/sq.cm) 2-4
Air consumption of rated pressure lit/min (c.f.m) 340-370 (12-13)
Max. pattern width (mm) 430
Min. Air-compressor (HP) 2
Weight of gun with cup (gms) 695
